Airtac GC FRL Unit GC20006F1
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Triple Unit GC20006F1 Technical Specifications
- Model: GC20006F1
- Type: Filter-Regulator-Lubricator (FRL) combination unit
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Filtration grade: 5 μm (auto-drain version)
- Pressure regulation range: 0.05–0.85 MPa
- Oil cup capacity: 130 cm³
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Flow capacity: 2000 L/min (ANR)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 650g ±5%
- Dimensions: 160mm(L) × 70mm(W) × 70mm(H)
- Installation orientation: Vertical mounting required
Integrated air preparation unit combining precision filtration (40μm stainless steel mesh), pressure regulation with lockable knob, and adjustable lubrication (0-8 drops/min). Features manual bypass for emergency operation and transparent bowl with splash guard. Includes built-in pressure gauge (MPa/psi dual scale) with protective rubber ring.
- Pneumatic production line header systems
- CNC machine tool pneumatic circuits
- Automotive assembly line tooling
- Food packaging machinery (oil-free version available)
- Industrial robot end-effector supply systems
Maintenance protocol:
Drain condensate daily via bottom auto-drain. Replace filter element every 2,000 operational hours.
Use ISO VG32 turbine oil for lubrication. Avoid mounting near heat sources (>60℃ ambient).
| Property | Property Value |
|---|---|
| sku | GC20006F1 |
| Port Size | PT1/8 |
