Airtac GC FRL Unit GC20006F1K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series FRL Combination Unit GC20006F1K Technical Details
- Model: GC20006F1K (Triple Unit)
- Configuration: Filter + Regulator + Lubricator with Bracket
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 2000 L/min (ANR)
- Filter element: 5μm precision (40μm optional)
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Body material: Die-cast aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 70℃
- Weight: 1.8 kg (complete assembly)
- Dimensions: 180mm(W) × 150mm(H) × 95mm(D)
- Drain type: Manual float drain
- Lubricator oil capacity: 180cc
- Mounting: Panel bracket with M5 mounting holes
Integrated pneumatic conditioning unit combining three essential functions: particulate filtration (5μm), precise pressure regulation (±0.02MPa stability), and adjustable aerosol lubrication (2-3 drops/min). Features anti-corrosion aluminum housing with transparent polycarbonate bowls for visual monitoring. The compact modular design allows vertical or horizontal installation in confined spaces.
- Pneumatic tool air line conditioning
- CNC machine pneumatic systems
- Automated assembly line actuators
- Packaging machinery air preparation
- Robotic arm control systems
Maintenance protocol:
Replace filter element every 6 months under normal load (2000hr operation).
Maintain oil level above 1/3 capacity in lubricator. Drain condensate daily
when ambient humidity exceeds 60%. Install downstream of air dryer for
moisture-sensitive applications.
| Property | Property Value |
|---|---|
| sku | GC20006F1K |
| Port Size | PT1/8 |
