Airtac GC FRL Unit GC20006F1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Triple Unit GC20006F1W Technical Specifications
- Model: GC20006F1W (Compact Combination Unit)
- Configuration: Filter + Regulator + Lubricator (FRL)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 2,500 L/min (ANR)
- Filter element: 5μm sintered bronze
- Regulator adjustment range: 0.05–0.9 MPa
- Lubricator oil capacity: 130 cm³
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy + polycarbonate
- Weight: 850g ±5% (dry)
- Dimensions: 180mm(H) × 100mm(W) × 65mm(D)
- Pressure gauge: Dual scale (MPa/psi) with anti-vibration design
- Drain type: Manual float drain
Integrated pneumatic conditioning unit combining precision filtration, pressure stabilization, and adjustable lubrication. Features a transparent bowl with anti-splash baffle and corrosion-resistant construction. The regulator includes a tamper-proof lock nut and zero-adjustment knob for stable pressure maintenance. Designed for industrial environments requiring ISO 8573-1 air quality compliance.
- Pneumatic production line main air supply conditioning
- CNC machine tool pneumatic systems
- Automated assembly line actuator control
- Food packaging machinery (oil-free version available)
- Semiconductor manufacturing equipment
Installation protocol:
Install in sequence F→R→L with minimum 300mm straight inlet piping.
Maintain vertical orientation (±15° tolerance). Lubricator requires ISO VG32-68 oil.
Drain filter daily under continuous operation conditions.
- Filter element replacement: 6-12 months (depending on condensate levels)
- Lubricator refill interval: 1,500 operating hours (standard conditions)
- Diaphragm inspection: Every 2 years or 10,000 hours
| Property | Property Value |
|---|---|
| sku | GC20006F1W |
| Port Size | PT1/8 |
