Airtac GC FRL Unit GC20006F3K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Triple Unit GC20006F3K Technical Details
- Model: GC20006F3K (Integrated FRL Unit)
- Component configuration: Filter + Regulator + Lubricator
- Port size: PT1/4 (G1/4 BSPP equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 1,200 L/min (ANR)
- Filter rating: 40μm (5μm optional element available)
- Regulator accuracy: ±0.02 MPa
- Lubricator oil capacity: 120cm³
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.35 kg (with bracket)
- Dimensions: 180mm(W) × 135mm(H) × 85mm(D)
- Mounting: Panel bracket or inline piping
- Drain type: Manual float drain
Modular FRL unit combining precision air preparation functions with industrial-grade durability. Features dual-chamber filter bowl with impact-resistant PC cover, precision pressure gauge with pulsation damper, and adjustable oil drip rate (2-3 drops/min). Includes anti-backflow check valve and metal bowl guard.
- Pneumatic production line main air conditioning
- CNC machine tool pneumatic systems
- Automated assembly line actuator groups
- Plastic injection molding machines
- Textile machinery air circuits
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricator requires ISO VG32 turbine oil. Bowl torque specification: 8-10 N·m.
| Property | Property Value |
|---|---|
| sku | GC20006F3K |
| Port Size | PT1/8 |
