Airtac GC FRL Unit GC20006F3W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC20006F3W Triple Unit (F.R.L.) Technical Specifications
- Model: GC20006F3W
- Type: Filter-Regulator-Lubricator combination
- Thread size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15-1.0 MPa
- Filtration rating: 5 μm (40μm optional element available)
- Pressure regulation range: 0.05-0.85 MPa
- Oil capacity: 120ml (with visible oil level window)
- Body material: Aluminum alloy (filter bowl: polycarbonate)
- Temperature range: -10℃ to 60℃
- Weight: 1.2 kg (including mounting bracket)
- Dimensions: 160mm(H) × 80mm(W) × 120mm(D)
- Drain type: Manual drain with anti-splash guard
- Pressure gauge: 2" dial with MPa/psi dual scale
- Adjustment knob: Lockable rotary type with torque ≤1.5N·m
Integrated pneumatic conditioning unit combining 3-stage air preparation: mechanical filtration (with 180° bowl orientation), precision pressure regulation, and adjustable oil mist lubrication. Features a shatter-resistant transparent bowl with safety guard, corrosion-resistant anodized components, and tool-free bowl removal. Designed for continuous operation in industrial environments.
- Production line pneumatic tool stations
- CNC machine tool pneumatic systems
- Automated packaging machinery air supply
- Plastic injection molding machine air prep
- Food processing pneumatic circuits (using food-grade lubricant)
Maintenance protocol:
Drain condensate daily in high-humidity environments. Replace filter element every 2,000 operational hours.
Lubricator oil flow adjustment: 1 drop/10 cycles (rotate knob 90°=0.5cc/min output).
| Property | Property Value |
|---|---|
| sku | GC20006F3W |
| Port Size | PT1/8 |
