Airtac GC FRL Unit GC20006LC1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006LC1W Technical Details
- Model: GC20006LC1W (Compact Aluminum Body Series)
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Maximum flow: 2000 L/min (ANR)
- Filter micron rating: 5μm (40μm optional with auto-drain)
- Lubricator oil capacity: 180cc
- Drain type: Manual/auto drain (model-specific)
- Weight: 1.65 kg (with full oil)
- Dimensions: 195mm(W) × 165mm(H) × 115mm(D)
- Body material: Anodized aluminum alloy
- Seal material: NBR/FKM (optional Viton)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" BSPT dial (0-1.6MPa range)
- Protection rating: IP42 (standard)
Modular FRL unit featuring integrated pressure regulation with lockable knob and visible oil level window. The dual-chamber filter bowl includes a splash guard for consistent lubrication. Designed for compressed air pretreatment with optional differential pressure indicator (add-on accessory). Requires upstream installation of 0.01μm coarse filter for optimal performance.
- Pneumatic tool supply lines in automotive assembly
- CNC machine air preparation systems
- Packaging machinery moisture control
- Food processing pneumatic circuits (FDA-grade oil option)
- Robotic actuator air conditioning
Installation protocol:
Mount vertically with arrow marking airflow direction. Maintain 20cm clearance below
for bowl removal. Lubricator should be positioned last in the FRL sequence. Replace
filter element every 4,000 operating hours or when ΔP exceeds 0.1MPa.
| Property | Property Value |
|---|---|
| sku | GC20006LC1W |
| Port Size | PT1/8 |
