Airtac GC FRL Unit GC20006LF1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006LF1W Technical Specifications
- Full model code: GC20006LF1W
- Component configuration: Filter-Regulator-Lubricator (FRL) assembly
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.15-1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration grade: 5 μm (with 70% efficiency at 3 μm)
- Flow capacity: 2000 L/min (ANR)
- Oil capacity: 180 cm³ (polycarbonate bowl)
- Temperature range: 2℃ to 60℃ (non-freezing conditions)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR (nitrile rubber)
- Weight: 540 g ±2% (without lubricant)
- Dimensions: 165mm(W) × 72mm(H) × 90mm(D)
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Drain type: Manual push-button with anti-drip shield
- Mounting: Panel bracket with M5 slot
Integrated pneumatic conditioning unit combining precision filtration (40μm stainless steel mesh + fiber element), pressure regulation (±0.02 MPa stability), and adjustable oil mist lubrication (0-8 drops/min). Features automatic drain backup for high humidity environments and transparent bowls with metal guards. Meets ISO 8573-1:2010 class 4 particulate requirements.
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Plastic injection molding machines
- Textile machinery air preparation
- Packaging equipment pneumatic circuits
Installation protocol:
Install vertically within 5° of upright position. Maintain 50mm clearance below bowl for drainage access.
Lubricator should be positioned last in the FRL sequence. Replace filter element every 2,000 operational hours
in normal conditions (ISO 8573-2 class 4 environment).
| Property | Property Value |
|---|---|
| sku | GC20006LF1W |
| Port Size | PT1/8 |
