Airtac GC FRL Unit GC20006MC1K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series F.R.L. Unit GC20006MC1K Technical Specifications
- Model: GC20006MC1K
- Type: 3-in-1 Combination Unit (Filter + Regulator + Lubricator)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Maximum pressure: 1.0 MPa
- Filter rating: 5μm (auto-drain version)
- Regulator accuracy: ±0.05 MPa
- Lubricator capacity: 200cc (adjustable 0-10 drops/min)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Material: Aluminum alloy body, polycarbonate bowl
- Weight: 1.2kg (with full lubricant)
- Dimensions: 200mm(L) × 100mm(W) × 150mm(H)
- Thread torque rating: 15N·m max
- Flow capacity: 2000NL/min (ANR)
- Drain type: Semi-automatic float drain
Modular pneumatic conditioning unit combining precision filtration (40μm sintered element), pressure stabilization with lockable knob, and visual oil-feed control. Features impact-resistant bowl guard and corrosion-resistant internals. Includes mounting bracket slots for horizontal/vertical installation.
- Pneumatic tool air preparation systems
- Packaging machinery main air lines
- CNC machine pneumatic circuits
- Automated assembly line actuators
- Textile machinery lubrication systems
Maintenance protocol:
Replace filter element every 6,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricant viscosity should match ISO VG32-68 standards. Bowl requires monthly inspection for microcracks.
| Property | Property Value |
|---|---|
| sku | GC20006MC1K |
| Port Size | PT1/8 |
