Airtac GC FRL Unit GC20006MC1WK
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006MC1WK Technical Details
- Model: GC20006MC1WK
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.6 MPa
- Flow capacity: 2000 L/min (ANR)
- Filter grade: 5μm (with auto-drain)
- Regulator accuracy: ±0.2 MPa
- Lubricator oil capacity: 200cc
- Weight: 1.8kg (dry)
- Dimensions: 180mm(H) × 130mm(W) × 100mm(D)
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR/PU compound
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 63mm dial (glycerin-filled)
- Mounting: Bracket type (panel mount optional)
Industrial-grade air preparation unit combining precision filtration (with manual/auto drain), pressure regulation with lockable knob, and adjustable oil mist lubrication. Features corrosion-resistant construction with transparent bowls for visual monitoring. Integrated mounting bracket allows vertical or horizontal installation.
- Pneumatic tool air line conditioning
- CNC machine pneumatic systems
- Automated assembly line main air supply
- Packaging machinery air circuit protection
- Robotic actuator systems
Installation protocol:
Install in sequence (filter→regulator→lubricator) with minimum 300mm
straight inlet piping. Lubricator requires ISO VG32 oil. Replace filter
element every 4,000 operational hours or when pressure drop exceeds 0.1MPa.
| Property | Property Value |
|---|---|
| sku | GC20006MC1WK |
| Port Size | PT1/8 |
