Airtac GC FRL Unit GC20006MF1
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006MF1 Technical Details
- Model: GC20006MF1 (Compact Modular Design)
- Configuration: Filter + Regulator + Lubricator (FRL)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow: 2000 L/min (ANR)
- Filter rating: 40μm (5μm optional element)
- Regulator accuracy: ±0.2 bar
- Lubricator oil capacity: 180cc
- Weight: 1.2 kg (with bracket)
- Dimensions: 165mm(W) × 145mm(H) × 85mm(D)
- Body material: Die-cast aluminum (anodized)
- Seal material: HNBR (high-grade oil-resistant)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual/auto drain options
- Pressure gauge: 1/8" dial type (MPa/psi dual scale)
Modular FRL unit with integrated mounting bracket and shock-resistant gauge. Features transparent polycarbonate bowls with metal guards, auto-drain float mechanism (optional), and precision pressure regulation knob with lock function. Designed for industrial air preparation with 360° rotatable ports for flexible piping.
- CNC machine pneumatic systems
- Automated assembly line tooling
- Packaging machinery air circuits
- Robotic actuator supply lines
- Plastic injection molding machines
Maintenance protocol:
Replace filter element every 6,000 operational hours or when differential pressure exceeds 0.1MPa.
Lubricator requires ISO VG32 oil refill every 3 months under continuous use. Always install downstream
of directional control valves with arrow alignment check.
| Property | Property Value |
|---|---|
| sku | GC20006MF1 |
| Port Size | PT1/8 |
