Airtac GC FRL Unit GC20006MF1K
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006MF1K Technical Specifications
- Model: GC20006MF1K (Integrated FRL Unit)
- Port size: PT1/2 (BSPP thread)
- Filter rating: 40μm (5μm optional with coalescing filter)
- Pressure regulation range: 0.05–0.85 MPa
- Max operating pressure: 1.0 MPa
- Flow capacity: 3,000 L/min (ANR)
- Lubricator capacity: 180cc (transparent polycarbonate bowl)
- Drain type: Manual float drain
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.85 kg (with full lubricant)
- Dimensions: 210mm(H) × 130mm(W) × 85mm(D)
- Materials: Die-cast aluminum body, NBR seals
- Pressure gauge: 63mm dial (MPa/psi dual scale)
- Mounting: Bracket-integrated design (ISO 4414 compliant)
Modular FRL unit combining precision filtration (with water separator), pressure regulation with lockable knob, and adjustable lubricator. Features anti-vibration gauge, corrosion-resistant bowl guard, and tool-free bowl removal. Designed for industrial air preparation with visual maintenance indicators.
- CNC machine pneumatic systems
- Automated assembly line actuators
- Plastic injection molding machines
- Industrial robotics end effectors
- Pneumatic conveyor controls
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricator oil viscosity should match ambient temperature (ISO VG32 recommended for 20-40℃ environments).
| Property | Property Value |
|---|---|
| sku | GC20006MF1K |
| Port Size | PT1/8 |
