Airtac GC FRL Unit GC20006MF1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series Trio Unit GC20006MF1W Technical Specifications
- Model: GC20006MF1W
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa
- Maximum pressure: 1.0 MPa
- Filter micron rating: 5μm (40μm optional element available)
- Adjustable lubricator oil output: 0-15 drops/min
- Flow capacity: 2000 L/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (HNBR optional)
- Temperature range: -20℃ to 70℃ (non-freezing conditions)
- Weight: 1.25 kg ±5%
- Dimensions: 102mm(W) × 76mm(D) × 138mm(H)
- Drain type: Manual/auto drain options (specify when ordering)
- Pressure gauge: 40mm dial diameter (glycerin-filled optional)
- Mounting: Bracket-integrated design (ISO 4414 compliant)
Modular FRL unit combining precision air preparation functions with corrosion-resistant construction. Features dual-chamber filter bowl with impact baffle and transparent polycarbonate cover. The regulator incorporates a balanced diaphragm design for stable output under fluctuating supply pressures. Lubricator includes anti-backflow check valve and adjustable metering needle.
- Pneumatic automation lines in automotive assembly
- Packaging machinery air preparation systems
- Food processing equipment (food-grade lubricant compatible)
- Industrial robot end-effector control systems
- Semiconductor manufacturing cleanroom environments
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction. Maintain minimum 30cm upstream straight piping.
Lubricator should be positioned ≤5 meters from point-of-use. Replace filter element when pressure drop exceeds 0.05MPa.
| Property | Property Value |
|---|---|
| sku | GC20006MF1W |
| Port Size | PT1/8 |
