Airtac GC FRL Unit GC20006MF1WK
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series FRL Combination Unit GC20006MF1WK Technical Details
- Full model code: GC20006MF1WK
- Configuration: Filter + Regulator + Lubricator (FRL) combo
- Port size: PT1/2 (BSPP thread)
- Max operating pressure: 1.5 MPa
- Working pressure range: 0.1-1.0 MPa
- Filter rating: 5μm (replaceable sintered bronze element)
- Regulator accuracy: ±0.2 bar
- Oil capacity: 180cm³ (with drip-feed adjustment)
- Body material: Anodized aluminum alloy
- Seals: NBR (standard), optional Viton
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Drain type: Manual float drain
- Weight: 1.85 kg (dry, without accessories)
- Dimensions: 155mm(H) × 110mm(W) × 90mm(D)
- Mounting: Bracket mounting with 32mm spacing
Modular triple-function unit combining air preparation components for industrial pneumatic systems. Features a corrosion-resistant aluminum body with transparent bowl for visual monitoring. The integrated design reduces piping complexity while maintaining individual component serviceability. Includes pressure gauge port and tool-free bowl removal.
- Centralized air preparation in CNC machining centers
- Production line pneumatic tool stations
- Plastic injection molding machine air circuits
- Automated assembly line actuator systems
- Food processing pneumatic controls (with food-grade lubricant)
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricator refill interval: 8-12 weeks under normal use. Always depressurize system before
servicing. Compatible with ISO VG32 pneumatic oils.
| Property | Property Value |
|---|---|
| sku | GC20006MF1WK |
| Port Size | PT1/8 |
