Airtac GC FRL Unit GC20006MF3
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC20006MF3 Triple Unit (FRL) Specifications
- Model: GC20006MF3
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.9 MPa
- Maximum flow: 1,000 L/min (ANR)
- Filter rating: 5 μm (with auto-drain)
- Regulator accuracy: ±0.05 MPa
- Lubricator oil capacity: ~50 mL
- Weight: ~450g (dry)
- Dimensions: 120mm(L) × 80mm(W) × 80mm(H)
- Body material: Aluminum alloy (filter bowl: polycarbonate)
- Seal material: NBR
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 1/8" dial type (0-1.0 MPa scale)
Integrated compressed air treatment unit combining precision filtration, pressure stabilization, and adjustable lubrication. Features a transparent bowl with splash guard design and one-touch bowl removal. The regulator includes a tamper-proof cover and lockable knob. Filter bowl includes a debris separator with 180° rotation capability.
- Pneumatic production line air preparation
- CNC machine tool pneumatic systems
- Automated assembly equipment
- Industrial robot end-effector control
- Packaging machinery air supply conditioning
Installation note:
Install vertically with flow arrow alignment. Maintain 50mm clearance below bowl for drainage access.
Lubricator should be positioned last in the FRL sequence. Replace filter element every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | GC20006MF3 |
| Port Size | PT1/8 |
