Airtac GC FRL Unit GC20006MLC1W
2. 360° rotary oil flow adjustment ring with linear flow gradient, allowing approximate oil output estimation through calibrated indexing;
3. In-line oil replenishment without interrupting airflow;
4. Specialized nozzle design generates negative pressure at outlet port, minimizing mist formation;
5. Quick-connect interface enables secure installation and maintenance efficiency;
6. Pressure regulation maintains stability with high repeatability accuracy;
7. High-efficiency removal of moisture and solid particulates;
8. Optional drainage configurations: manual, differential pressure-activated, or automatic discharge.
Category: Air Treatment Units | Brand: Airtac | Series: GC
AirTAC GC Series F.R.L. Combination Unit GC20006MLC1W Specifications
- Model: GC20006MLC1W
- Type: Filter-Regulator-Lubricator (F.R.L) unit with auto-drain
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.05–1.0 MPa
- Filtration grade: 40μm (5μm optional element available)
- Maximum flow rate: 2,000 L/min
- Pressure gauge range: 0–1.6 MPa
- Drain type: Semi-automatic float drain
- Body material: Die-cast aluminum with epoxy coating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃
- Weight: 1.2 kg (including mounting bracket)
- Dimensions: 180mm(L) × 120mm(W) × 65mm(H)
- Mounting: Panel or bracket installation
Industrial-grade triple function unit combining precision air preparation components. Features a corrosion-resistant aluminum body with dual-scale pressure gauge (MPa/psi) and visible bowl design for maintenance monitoring. The integrated bypass mechanism ensures continuous operation during filter element replacement.
- Pneumatic system air treatment in packaging machinery
- Compressed air conditioning for automotive assembly lines
- Centralized air supply systems in semiconductor manufacturing
- Workshop air line maintenance stations
- Textile machinery lubrication control
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below drain port for maintenance access.
Recommended replacement cycle: Filter element every 4,000 hours
or when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GC20006MLC1W |
| Port Size | PT1/8 |
