Airtac GFC Combination Unit GFC20006LC1
2、Stable pressure regulation with high repeatability accuracy (±0.5% F.S.);
3、High-efficiency moisture separation (95%+ water removal) and solid particle separation efficiency (5μm filtration);
4、Three drainage configurations: manual, differential pressure-activated, and automatic drainage modes.
Category: F.R.L. Combination Units , Brand: AIRTAC , Series: GFC
AirTAC GFC Series Combination Unit GFC20006LC1 Technical Details
- Model: GFC20006LC1
- Type: Compact 2-in-1 unit (Filter + Regulator)
- Port size: PT3/8 (G1/2 optional)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 3,500 L/min (ANR)
- Filtration grade: 5μm (40μm optional)
- Pressure gauge: Built-in 1/8" dial gauge
- Adjustment range: 0.05–0.85 MPa
- Weight: 1.2kg ±5%
- Dimensions: 180mm(L) × 120mm(W) × 120mm(H)
- Bowl material: Transparent polycarbonate
- Body material: Die-cast aluminum (anodized)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Auto-drain: Manual/float-type optional
- Mounting: Bracket or panel mount
Professional-grade air preparation unit integrating precision filtration and pressure regulation. Features a visible bowl with anti-static coating and safety lock ring. The dual-stage design reduces pressure drop by 15% compared to standard units. Requires 7-10 bar compressed air input.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery pressure stabilization
- Automotive assembly line tooling
Maintenance protocol:
Drain condensate daily when humidity >60%. Replace filter element every
2,000 operational hours. Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | GFC20006LC1 |
| Port Size | PT1/8 |
