Airtac GFC Combination Unit GFC20006LC1W
2、Stable pressure regulation with high repeatability accuracy (±0.5% F.S.);
3、High-efficiency moisture separation (95%+ water removal) and solid particle separation efficiency (5μm filtration);
4、Three drainage configurations: manual, differential pressure-activated, and automatic drainage modes.
Category: F.R.L. Combination Units , Brand: AIRTAC , Series: GFC
AirTAC GFC Series FRL Combination Unit - GFC20006LC1W Technical Details
- Model: GFC20006LC1W
- Type: Compact filter regulator lubricator (FRL) combination
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.05–1.0 MPa
- Maximum flow: 2000 L/min
- Weight: ~1.2 kg (with bracket)
- Dimensions: 200mm(L) × 120mm(W) × 160mm(H)
- Filter element: 40μm sintered bronze
- Regulator accuracy: ±0.2 bar
- Lubricator oil capacity: 100cc
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Manual/auto hybrid (float-type)
- Material: Die-cast aluminum body with polycarbonate bowl
- Pressure gauge: Dual scale (bar/psi)
- Protection rating: IP54 (bowl excluded)
Integrated air preparation unit combining precision filtration (40μm), pressure regulation (±0.2% FS), and adjustable lubrication. Features a shatter-resistant bowl with safety guard and dual pressure scales. The angled bracket design allows vertical/horizontal mounting in confined spaces.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Packaging machinery air circuit conditioning
- Automated assembly line tooling stations
- Plastic injection molding machine air prep
Installation protocol:
Mount upstream of pneumatic components (recommended 500mm from actuators).
Maintain vertical bowl orientation. Lubricator requires ISO VG32 oil.
Perform daily bowl drainage - rotate drain knob 45° until airflow stops.
| Property | Property Value |
|---|---|
| sku | GFC20006LC1W |
| Port Size | PT1/8 |
