Airtac GFC Combination Unit GFC20006MC1K
2、Stable pressure regulation with high repeatability accuracy (±0.5% F.S.);
3、High-efficiency moisture separation (95%+ water removal) and solid particle separation efficiency (5μm filtration);
4、Three drainage configurations: manual, differential pressure-activated, and automatic drainage modes.
Category: F.R.L. Combination Units , Brand: AIRTAC , Series: GFC
AirTAC GFC Series Filter Regulator Combo Unit GFC20006MC1K Technical Details
- Full model designation: GFC20006MC1K
- Configuration: Filter regulator combination (F.R.L. unit without lubricator)
- Port size: PT1/4 (BSPP 1/4") with dual female threads
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Filter micron rating: 40μm (5μm optional element available)
- Pressure gauge: Integrated 1/8" dial gauge 0-1.6MPa range
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Drain type: Semi-automatic push-button drain with anti-splash shield
- Body material: Die-cast aluminum alloy with epoxy coating
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Flow capacity: 3,500 Nl/min (at 0.7MPa)
- Weight: 820g ±2% (dry condition)
- Dimensions: 148mm(H) × 98mm(W) × 212mm(D)
- Mounting: Panel mount with 32mm bracket spacing
- Compliance: RoHS 2011/65/EU, REACH (SVHC < 0.1%)
Professional-grade pneumatic conditioning unit combining precision filtration and pressure regulation. Features a transparent polycarbonate bowl with metal guard for visual debris monitoring. The chrome-plated adjustment knob includes tamper-proof security slots, while the dual-chamber design minimizes pressure drop. Optimized for ISO 8573-1:2010 [2:4:2] air quality standards.
- Centralized pneumatic systems in semiconductor manufacturing
- Plastic injection molding machine air preparation
- Automated assembly line tooling stations
- CNC machine tool clamping circuits
- Food packaging equipment (using food-grade lubricants)
Maintenance protocol:
Drain condensate daily via the quick-release button. Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05MPa. Bowl torque specification: 8-10Nm during servicing.
| Property | Property Value |
|---|---|
| sku | GFC20006MC1K |
| Port Size | PT1/8 |
