Airtac GFR Filter Regulator GFR20006C1
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006C1 Pressure Regulating Filter Detailed Specifications
- Model: GFR20006C1 (Metal bowl version)
- Port size: PT1/4 (G1/4 optional)
- Filtration grade: 40μm (5μm optional with different filter element)
- Pressure regulation range: 0.05–0.85 MPa
- Max flow rate: 2000 L/min (ANR)
- Operating temperature: -5℃ to 60℃ (non-freezing)
- Bowl material: Die-cast aluminum with transparent PC window
- Seal material: NBR (Nitrile rubber)
- Weight: 450g ±5% (dry, without mounting bracket)
- Dimensions: 105mm(H) × 60mm(W) × 80mm(D)
- Pressure gauge port: M5 threaded (optional gauge accessory)
- Drain type: Manual drain with splash guard
- Mounting: Bracket rotation 340° adjustable
- Max inlet pressure: 1.5 MPa
Industrial-grade combination unit integrating 40μm filtration and precision pressure regulation. Features a metal bowl with impact-resistant window for sludge inspection. The T-handle regulator allows tool-free adjustment with ±2% pressure stability. Bowl incorporates vortex separator for enhanced water removal efficiency.
- Pneumatic tool air preparation stations
- CNC machine pneumatic control systems
- Packaging line actuator clusters
- Food processing air supply lines (FDA-compliant versions available)
- Robotic arm end-effector controls
Maintenance protocol:
Replace filter element every 6-12 months depending on humidity levels.
Always depressurize system before bowl removal. Recommended vertical
installation with downward-facing drain port.
| Property | Property Value |
|---|---|
| sku | GFR20006C1 |
| Port Size | PT1/8 |
