Airtac GFR Filter Regulator GFR20006C1K
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR Series Filter Regulator GFR20006C1K Technical Details
- Model: GFR20006C1K (Integrated Filter/Regulator/Lubricator)
- Port size: PT1/4 (BSPP) with 6mm push-in fitting
- Filter rating: 5μm particulate removal efficiency ≥95%
- Pressure regulation range: 0.05–0.85 MPa (7–123 PSI)
- Maximum flow capacity: 2000 NL/min (ANR)
- Pressure gauge interface: M5×0.8 threaded
- Body material: Anodized aluminum alloy
- Seal material: Oil-resistant NBR
- Operating temperature: -5℃ to 60℃ (non-freezing)
- Weight: ~530g (with bowl)
- Dimensions: Ø70mm × 110mm(H) (Bowl diameter × total height)
- Drain type: Manual drain button with splash guard
- Pressure gauge: 40mm dial with dual-scale (MPa/PSI)
- Protection rating: IP40 (bowl excluded)
- Mounting: Bracket slot for 25mm panel
Triple-function FRL unit combining 5μm particulate filtration, precision pressure regulation (with lockable knob), and optional oil mist lubrication. Features a transparent polycarbonate bowl with anti-static coating and metal guard ring. The C1K variant includes a 0.5L lubricator reservoir with drip-feed adjustment. Designed for systems requiring stable pressure output and contaminant protection.
- Pneumatic tool supply lines in automotive assembly
- Packaging machinery air preparation systems
- Food processing equipment (use food-grade lubricant)
- CNC machine pneumatic controls
- Plastic injection molding air circuits
Maintenance protocol:
Drain condensate daily in high-humidity environments. Replace filter element every 2,000 operational hours.
Lubricator oil level should remain between 1/4 and 3/4 capacity. Bowl torque specification: 3.5-4.5 N·m.
| Property | Property Value |
|---|---|
| sku | GFR20006C1K |
| Port Size | PT1/8 |
