Airtac GFR Filter Regulator GFR20006C3
$32.53
Regular price
$40.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GFR20006C3
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
GFR Series Pressure Regulating Filter - Product Features
1. Integrated recessed square pressure gauge for space-saving installation (optional external circular gauge available);
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
Installation guidelines:
Mount vertically with arrow indicating flow direction. Perform daily bowl drainage.
For optimal performance: 1) Pre-filter upstream with 5μm unit 2) Lubricate downstream
using GFR-L06 add-on kit if required 3) Adjust pressure clockwise with system running.
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR Series Pressure Regulating Filter GFR20006C3 Technical Details
- Model: GFR20006C3
- Type: Combined pressure regulator + 40μm filter
- Port size: PT1/4 (BSPP thread)
- Filtration rating: 40 microns (replaceable sintered element)
- Adjustment range: 0.05-0.85 MPa
- Max flow capacity: 2000 L/min (ANR)
- Body material: Aluminum alloy (anodized finish)
- Bowl material: Polycarbonate (PC) with metal guard
- Seal material: NBR (nitrile rubber)
- Operating temperature: 5℃ to 60℃ (non-freezing)
- Storage temperature: -10℃ to 70℃
- Weight: 480g ±2% (including bowl)
- Dimensions: 100mm(H) × 52mm(W) × 85mm(D)
- Pressure gauge: Integrated 1/8" NPT gauge port
- Drain type: Manual push-button condensate ejector
Dual-function unit combining precise pressure regulation with particulate filtration, featuring a visible bowl for maintenance monitoring. The anti-vibration diaphragm ensures stable output pressure under fluctuating input conditions. Compatible with ISO 8573-1 air quality standards.
Typical Applications:
- Pneumatic tool air line conditioning
- Packaging machinery air preparation systems
- Food processing equipment (FDA-compliant versions available)
- Semiconductor manufacturing clean air supply
- Medical device pneumatic controls
Installation guidelines:
Mount vertically with arrow indicating flow direction. Perform daily bowl drainage.
For optimal performance: 1) Pre-filter upstream with 5μm unit 2) Lubricate downstream
using GFR-L06 add-on kit if required 3) Adjust pressure clockwise with system running.
| Property | Property Value |
|---|---|
| sku | GFR20006C3 |
| Port Size | PT1/8 |
