Airtac GFR Filter Regulator GFR20006F1W
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR Pressure Regulating Filter GFR20006F1W Specifications
- Model: GFR20006F1W
- Type: Combined pressure regulator + 5μm filter
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 2,500 L/min (ANR)
- Filtration grade: 5μm (replaceable sintered bronze element)
- Drain type: Automatic condensate discharge
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa range)
- Adjustment knob: Lockable rotary knob with ±0.02 MPa stability
- Body material: Anodized aluminum alloy
- Bowl material: Polycarbonate (transparent)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 298g ±5g (dry)
- Dimensions: 104mm(H) × 50mm(W) × 50mm(D)
- Installation orientation: Vertical mounting required
Professional-grade combination unit integrating precision pressure regulation and particulate filtration. Features a shatter-resistant polycarbonate bowl with 180° visibility and one-touch bowl removal. The stainless steel bypass mechanism ensures continuous operation during element replacement. Designed for ISO 8573-1:2010 Class 4 air quality compliance.
- Pneumatic tool air supply stations
- Packaging machine main line conditioning
- CNC machine air preparation units
- Food processing pneumatic systems (oil-mist free)
- Laboratory instrument air purification
Maintenance protocol:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.05 MPa.
Daily manual drain recommended for high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GFR20006F1W |
| Port Size | PT1/8 |
