Airtac GFR Filter Regulator GFR20006F1WK
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006F1WK Filter Regulator Specifications
- Model: GFR20006F1WK
- Type: Combined air filter regulator with pressure gauge
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.85 MPa
- Maximum flow rate: 200 L/min
- Filtration grade: 5 μm (replaceable sintered bronze element)
- Water removal efficiency: ≥95% (at 0.7 MPa)
- Body material: Anodized aluminum alloy
- Bowl material: Impact-resistant polycarbonate
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.62 kg (with bowl)
- Dimensions: 120mm(L) × 80mm(W) × 120mm(H)
- Pressure gauge: Integrated 40mm dial (0-1.0 MPa scale)
- Drain type: Manual blow-down with deflector
Professional-grade pneumatic conditioning unit combining 3-stage filtration (centrifugal, baffle, and element filtration) with precision pressure regulation. Features a transparent bowl with anti-static coating to prevent particle adhesion. The ergonomic T-handle allows tool-free adjustment with ±1% pressure regulation accuracy.
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Packaging line actuator control
- Food processing automation (FDA-compliant versions available)
- Laboratory compressed air stations
Installation protocol:
Mount vertically with arrow marking airflow direction. Maintain 200mm clearance below bowl for drainage access.
Pre-filter (60μm+) recommended for systems with heavy contamination. Replace element every 6-12 months depending on humidity levels.
| Property | Property Value |
|---|---|
| sku | GFR20006F1WK |
| Port Size | PT1/8 |
