Airtac GFR Filter Regulator GFR20006JF1WK
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006JF1WK Pressure Regulating Filter Specifications
- Model: GFR20006JF1WK
- Type: Combination filter regulator with pressure gauge
- Filtration grade: 5 μm (replaceable element)
- Pressure regulation range: 0.05–0.85 MPa
- Max. flow rate: 2,500 L/min (ANR)
- Port size: PT1/4 (BSPP thread)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Operating temperature: -20℃ to 60℃
- Drain type: Manual drain plug
- Gauge range: 0–1.0 MPa (swivel type)
- Weight: 0.58 kg
- Dimensions: 78mm(W) × 95mm(H) × 112mm(D)
- Pressure gauge diameter: 40mm
- Pressure adjustment knob torque: 0.3–0.5 N·m
Integrated filtration and pressure regulation unit featuring a 360° rotatable gauge and ergonomic locking knob. The dual-chamber design separates particle sedimentation (bottom) and pressure regulation (top), with a transparent bowl for visual contamination monitoring. Includes anti-vibration bracket for gauge protection.
- Pneumatic tool air line conditioning
- Packaging machinery main air supply
- CNC machine pneumatic circuits
- Automated assembly line pressure control
- Laboratory compressed air systems
Maintenance protocol:
Replace filter element every 3,000 operating hours or when pressure drop exceeds 0.05 MPa.
Drain condensate daily in high-humidity environments. Bowl torque specification: 1.2–1.5 N·m during reassembly.
| Property | Property Value |
|---|---|
| sku | GFR20006JF1WK |
| Port Size | PT1/8 |
