Airtac GFR Filter Regulator GFR20006JF2W
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006JF2W Pressure Regulating Filter Specifications
- Model: GFR20006JF2W
- Type: Combination filter regulator with auto-drain
- Port size: PT1/4 (BSP 1/4)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow rate: 3,500 L/min (ANR)
- Filtration grade: 40 μm (5 μm optional with micro-glass element)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0 MPa scale)
- Body material: Die-cast aluminum alloy (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 420 g ±5%
- Dimensions: 105mm(H) × 50mm(W) × 85mm(D)
- Mounting: Bracket slot for 25mm rail or direct screw installation
- Drain type: Semi-automatic float-operated with manual purge
- Pressure adjustment: T-handle with lock nut (360° rotation)
High-efficiency modular air preparation unit combining precision filtration and pressure stabilization. Features a cyclone separation chamber with debris collection bowl (60ml capacity) and anti-releasing adjustment mechanism. The transparent bowl includes a metal guard and has 270° visibility for maintenance checks. Engineered for systems requiring stable pressure output and moisture/oil mist removal.
- Pneumatic actuator control in assembly line robotics
- Air supply conditioning for CNC machine tool chucks
- Packaging machinery pressure stabilization systems
- Laboratory instrument air purification
- Dental chair pneumatic circuits
Maintenance protocol:
Replace filter element every 6,000 operational hours or when pressure drop exceeds 0.1 MPa.
Always depressurize system before rotating the bowl. Compatible with ISO 8573-1 Class 4 air quality standards.
| Property | Property Value |
|---|---|
| sku | GFR20006JF2W |
| Port Size | PT1/8 |
