Airtac GFR Filter Regulator GFR20006JF3W
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006JF3W Filter Regulator Specifications
- Model: GFR20006JF3W
- Type: Combination filter regulator with pressure gauge
- Port size: PT1/4 (BSPP thread)
- Filtration grade: 5μm (replaceable sintered bronze element)
- Pressure adjustment range: 0.05–0.85 MPa
- Max flow rate: 2000 L/min (ANR)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR rubber
- Operating temperature: 0℃ to 60℃ (non-freezing)
- Pressure gauge range: 0–1.0 MPa (glycerin-filled)
- Drain type: Manual drain with splash guard
- Mounting orientation: Vertical (±15° tolerance)
- Weight: ~320g (without accessories)
- Dimensions: 135mm(L) × 60mm(W) × 80mm(H)
Precision air preparation unit combining filtration and pressure regulation, featuring a shock-resistant gauge with vibration damping. The dual-chamber design separates particle collection (lower bowl) from pressure regulation (upper chamber), with bowl safety guard meeting ISO 4414 standards. Includes tamper-proof adjustment knob with lockable setting.
- Pneumatic actuator control in assembly lines
- Air tool pressure stabilization in manufacturing
- Packaging machinery air supply conditioning
- Laboratory instrument air purification
- CNC machine pneumatic systems
Maintenance note:
Replace filter element every 2,000 operational hours in normal conditions.
Drain condensate daily in high-humidity environments. Bowl torque specification: 3.5–4.0 N·m during servicing.
| Property | Property Value |
|---|---|
| sku | GFR20006JF3W |
| Port Size | PT1/8 |
