Airtac GFR Filter Regulator GFR20006JNW
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR Series Pressure Regulating Filter GFR20006JNW Technical Details
- Model: GFR20006JNW
- Type: Combined pressure regulator + 40μm filter
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–0.95 MPa
- Max flow rate: 2,000 L/min (ANR)
- Filter element: 40μm sintered stainless steel
- Body material: Anodized aluminum alloy
- Drain type: Manual/auto drain option
- Temperature range: -20℃ to 70℃ (non-freezing)
- Weight: ~350g (including mounting bracket)
- Dimensions: 80mm(L) × 60mm(W) × 80mm(H)
- Pressure gauge: Built-in 1/8" gauge port
- Adjustment knob: Lockable rotary type
- Seal material: NBR/FKM optional
- Protection rating: IP42 (standard)
Industrial-grade combination unit integrating precision pressure regulation and particulate filtration. Features a corrosion-resistant aluminum body with ergonomic pressure adjustment knob and visible pressure gauge. The dual-chamber design separates filtration and regulation stages for stable output. Includes vibration-dampening bracket and anti-clog drain mechanism.
- Pneumatic assembly line pressure stabilization
- CNC machine tool air preparation systems
- Packaging machinery air supply conditioning
- Robotic actuator protection circuits
- Food processing pneumatic controls
- Medical device air quality management
Maintenance note:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05MPa.
Always depressurize system before adjusting regulator. Mount vertically with arrow mark facing downstream.
| Property | Property Value |
|---|---|
| sku | GFR20006JNW |
| Port Size | PT1/8 |
