Airtac GFR Filter Regulator GFR20006JNWK
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006JNWK Pressure Regulator Filter Specifications
- Model: GFR20006JNWK
- Type: Combined filter regulator with gauge
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Maximum flow: 2000 L/min
- Filtration rating: 5 μm (with auto-drain)
- Pressure gauge range: 0–1.6 MPa
- Weight: 0.65 kg
- Dimensions: 135mm(L) × 75mm(W) × 75mm(H)
- Body material: Die-cast aluminum alloy
- Seal material: NBR/Viton optional
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Condensate drain: Semi-automatic plunger type
- Protection rating: IP42 (standard configuration)
High-efficiency modular air preparation unit combining 5μm filtration and precision pressure regulation. Features a 270° rotatable gauge with shock-resistant liquid filling and ergonomic pressure adjustment knob. The bowl incorporates a metal guard and visible sediment window with MAX fill indicator.
- Pneumatic tool air supply stations
- Food processing machinery air lines
- Packaging equipment pneumatic circuits
- Industrial robot end-effector controls
- Dental chair pneumatic systems
Installation note:
Mount vertically with bowl downward. Install upstream of lubricators.
Perform daily condensate drainage - pull drain ring until airflow becomes clear.
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05MPa.
| Property | Property Value |
|---|---|
| sku | GFR20006JNWK |
| Port Size | PT1/8 |
