Airtac GFR Filter Regulator GFR20006LC1
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR Series Pressure Regulating Filter GFR20006LC1 Specifications
- Model: GFR20006LC1
- Type: Auto-drain pressure regulator with 40μm filter
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.95 MPa
- Maximum flow rate: 3000 L/min (ANR)
- Filtering accuracy: 5 μm
- Pressure gauge interface: Rc1/8
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 520 g ±5%
- Dimensions: 105mm(H) × 60mm(W) × 88mm(D)
- Drain type: Semi-automatic float drain
- Pressure adjustment: T-handle with lock nut
- Protection rating: IP40
Combined air preparation unit integrating pressure regulation and particulate filtration, featuring a visible bowl with anti-burst design. The zinc alloy adjustment knob provides precise pressure control (±0.02 MPa stability), while the transparent polycarbonate bowl allows visual monitoring of filter contamination. Includes built-in silencer for exhaust air.
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Food processing pneumatic lines (non-lubricated)
- Automotive assembly line actuators
- Semiconductor manufacturing equipment
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Recommended maintenance: Drain accumulated water daily and replace filter element every 6 months under normal conditions (2000 operating hours).
| Property | Property Value |
|---|---|
| sku | GFR20006LC1 |
| Port Size | PT1/8 |
