Airtac GFR Filter Regulator GFR20006LC1W
2. Press-lock mechanism with self-retaining function prevents pressure setting deviations from external interference;
3. Balanced-design pressure regulation system ensures stable adjustment with minimal drift and superior pressure characteristics;
4. Low-pressure variant available (0.4MPa max adjustable pressure) alongside standard configuration;
5. Innovative vortex-inducing structure enhances liquid-gas separation efficiency and reliably filters solid particulates;
6. Selectable filtration precision: 5μm or 40μm;
7. Three drainage configurations: manual, differential pressure-activated, and automatic discharge;
8. Optional fixed mounting bracket for enhanced stability.
Category: Pressure Regulating Filters | Brand: AIRTAC | Series: GFR
AirTAC GFR20006LC1W Pressure Regulator Filter Specifications
- Model: GFR20006LC1W
- Type: Combination filter regulator with auto-drain
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow rate: 2000 L/min (ANR)
- Filtration grade: 5 μm (replaceable element)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.0 MPa scale)
- Body material: Aluminum alloy with epoxy coating
- Seal material: Nitrile rubber (NBR)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.85 kg ±3%
- Dimensions: 135mm(H) × 50mm(W) × 75mm(D)
- Drain type: Semi-automatic float drain
- Pressure adjustment: T-handle with lockable knob
- Installation orientation: Vertical ±15° tolerance
Integrated pneumatic conditioning unit combining precision filtration (99.9% 5μm particle removal) and pressure stabilization. Features anti-clogging sintered bronze pre-filter and corrosion-resistant bowl with safety shield. The dual-chamber design maintains consistent output during pressure adjustments.
- Pneumatic tool air supply stations
- CNC machine pneumatic control systems
- Packaging line actuator clusters
- Industrial painting equipment
- Food processing air knife systems
Maintenance note:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.05MPa.
Daily bowl drainage required in high-humidity environments.
Critical:
Install downstream of main air filter (recommended 40μm pre-filter).
Never exceed 0.9MPa input pressure. Use thread sealant on male ports only.
| Property | Property Value |
|---|---|
| sku | GFR20006LC1W |
| Port Size | PT1/8 |
