Airtac GPF Oil Mist Separator GPF200C06AD
2、Selectable filtration accuracy: 0.3μm or 0.01μm micron ratings;
3、Two configurations available: Integrated differential pressure/manual operation or automatic drainage systems;
4、Bowl materials include polycarbonate (PC), nylon, and metal options for diverse environmental compatibility;
5、Single-unit models support fixed bracket mounting, while modular assemblies integrate seamlessly with AIRTAC triple/double units.
Category: Oil Mist Separators | Brand: AIRTAC | Series: GPF
AirTAC GPF Oil Mist Separator GPF200C06AD Technical Specifications
- Model: GPF200C06AD
- Flow capacity: 200 L/min @ 0.7MPa
- Filtration grade: 0.3μm (99.5% efficiency at 0.3μm particles)
- Initial pressure drop: ≤0.02 MPa
- Max operating pressure: 1.0 MPa
- Temperature range: -10℃ to 60℃
- Connection type: PT 3/8 (BSPP) female threads
- Housing material: Anodized aluminum alloy
- Filter media: Multilayer glass fiber with nano-coating
- Drain type: Manual drain valve with anti-splash shield
- Weight: 1.25 kg (with mounting bracket)
- Dimensions: 215mm(H) × 102mm(Dia) × 150mm(Width with bracket)
- Maintenance cycle: 4,000 hours (under ISO 8573-1 class 3 air quality)
- Certification: ISO 12500-1 compliant, CE/RoHS marked
High-efficiency coalescing filter designed for compressed air systems requiring ISO Class 2 oil content levels. Features dual-stage separation: mechanical impaction removes bulk liquid, while depth loading filters sub-micron aerosols. The vortex generator extends filter life by 30% compared to standard models.
- CNC machine tool lubrication systems
- Laser cutting machine air preparation
- Pharmaceutical pneumatic conveying
- Food packaging air knives
- Automotive painting robots
- Semiconductor cleanroom air supply
Installation protocol:
Mount vertically downstream of aftercoolers (3-5 pipe diameters from compressor).
Install pressure gauge at outlet port. Precede with 5μm particulate filter.
Drain daily - maximum condensate capacity 15ml per cycle.
Avoid:
- Steam-containing air streams (requires pre-cooling below 40℃)
- Synthetic ester-based lubricants (compatibility check required)
- Pulsation frequencies above 2Hz (install pulsation damper if needed)
| Property | Property Value |
|---|---|
| sku | GPF200C06AD |
| Drain Type | Auto Drain |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Cup Material | Metal Cup |
| Water Cup Capacity | 19CC |
| Filtration Accuracy | 0.01μm |
