Airtac GPFR Pressure Regulating Precision Filter GPFR20006ALD
$69.76
Regular price
$77.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GPFR20006ALD
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Snap-on cap pressure gauge design saves installation space while featuring a magnified dial with clear legible scales;
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
Maintenance protocol:
Replace filter element every 6,000 operational hours or when differential pressure exceeds 0.1MPa.
Always depressurize system before rotating bowl. Use only AirTAC FV-5 replacement cartridges.
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006ALD Pressure-Regulating Precision Filter Technical Details
- Model: GPFR20006ALD
- Type: Integrated filter-regulator with auto-drain
- Filtration grade: 5μm (98% efficiency), 0.3μm optional
- Flow capacity: 2000 NL/min (ANR)
- Operating pressure range: 0.05–1.0 MPa
- Adjustment pressure range: 0.05–0.85 MPa
- Port size: PT3/4 (G3/4 ISO228/1 compliant)
- Body material: Die-cast aluminum (anodized finish)
- Bowl material: Polycarbonate (impact-resistant)
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Pressure gauge: Built-in 1.6MPa dial (63mm diameter)
- Weight: 1.85kg ±3% (dry condition)
- Dimensions: 160mm(W) × 165mm(H) × 135mm(D)
- Thread torque limit: 25N·m max
- Vibration resistance: 4.9m/s² @10–150Hz
- Protection rating: IP54 (bowl removed: IP40)
High-efficiency combination unit integrating 3-stage filtration (coalescing, gravity separation, and fine filtering) with precision pressure regulation. Features a visible sediment bowl with safety shield and tamper-proof adjustment knob. The dual-chamber design maintains consistent output pressure during pulsation events.
Industrial Applications:
- Laser cutting machine air preparation systems
- Pharmaceutical pneumatic conveying lines
- Semiconductor manufacturing cleanrooms
- Beverage filling station pressure control
- Robotic painting equipment air supply
Maintenance protocol:
Replace filter element every 6,000 operational hours or when differential pressure exceeds 0.1MPa.
Always depressurize system before rotating bowl. Use only AirTAC FV-5 replacement cartridges.
Mounting requirements:
Install vertically (±15° tolerance) downstream of main air receiver.
Allow 200mm clearance below bowl for drainage access.
Pre-filter with 40μm particulate filter if upstream oil content exceeds 10ppm.
| Property | Property Value |
|---|---|
| sku | GPFR20006ALD |
| Port Size | PT1/8 |
