Airtac GPFR Pressure Regulating Precision Filter GPFR20006ASM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR Precision Filter Regulator GPFR20006ASM Technical Details
- Model: GPFR20006ASM
- Type: Combination filter regulator with pressure gauge
- Port size: PT1/4 (BSP 1/4")
- Flow capacity: 2,000 NL/min (ANR)
- Filtration grade: 5 μm (replaceable element)
- Operating pressure: 0.05–1.0 MPa
- Max pressure: 1.5 MPa
- Pressure adjustment range: 0.05–0.85 MPa
- Condensate capacity: 1.8 cm³
- Body material: Die-cast aluminum (anodized finish)
- Bowl material: Polycarbonate (impact-resistant)
- Seal material: NBR rubber
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 560g ±2%
- Dimensions: 135mm(H) × 70mm(W) × 70mm(D)
- Gauge diameter: 40mm (dual scale: MPa/psi)
- Drain type: Manual drain plug (semi-automatic option available)
Industrial-grade combination unit integrating 5μm filtration and precision pressure regulation. Features a transparent bowl with anti-static coating to prevent dust adhesion. The dual-calibrated gauge allows simultaneous monitoring of input/output pressures. Designed for systems requiring stable air quality and pressure consistency.
- Pneumatic tool air preparation systems
- Automated assembly line air supply
- Food packaging machinery (FDA-compliant versions available)
- Semiconductor manufacturing cleanrooms
- Dental chair pneumatic systems
Maintenance protocol:
Replace filter element every 6 months under normal operation (ISO 8573-1 class 4).
Always depressurize system before bowl removal. Mount vertically with arrow
marking aligned to airflow direction (→).
| Property | Property Value |
|---|---|
| sku | GPFR20006ASM |
| Port Size | PT1/8 |
