Airtac GPFR Pressure Regulating Precision Filter GPFR20006ASNM
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006ASNM Precision Filter Regulator Specifications
- Model: GPFR20006ASNM
- Type: Combined filter regulator with pressure gauge
- Port size: PT1/4 (G1/4 optional)
- Filtration rating: 5 μm (98% efficiency at 0.3 μm)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 2000 L/min (ANR)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: NBR/Nitrile rubber
- Temperature range: -5℃ to 60℃ (non-freezing)
- Pressure gauge: 63mm dial, ±2% accuracy
- Weight: 680g ±5%
- Dimensions: 152mm(H) × 60mm(W) × 85mm(D)
- Drain type: Manual/auto drain optional
- Mounting: Panel or bracket (ISO 4414 compliant)
Integrated pneumatic solution combining micron-level filtration with precise pressure regulation. Features a large sediment bowl with anti-static coating and impact-resistant polycarbonate cover. The dual-stage design separates water/oil removal (first stage) from fine particle filtration (second stage). Includes a tamper-proof adjustment knob with lockable pressure setting.
- CNC machine pneumatic control systems
- Automated assembly line air preparation
- Laser cutting equipment gas regulation
- Pharmaceutical manufacturing clean air supply
- Robotic actuator pressure stabilization
Maintenance protocol:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.1MPa.
Always depressurize system before rotating the bowl for servicing.
| Property | Property Value |
|---|---|
| sku | GPFR20006ASNM |
| Port Size | PT1/8 |
