Airtac GPFR Pressure Regulating Precision Filter GPFR20006LJND
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006LJND Precision Pressure Regulating Filter Specifications
- Model: GPFR20006LJND
- Type: Combination filter regulator with pressure gauge
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Flow capacity: 2,500 L/min (ANR)
- Filtration grade: 5 μm (with auto-drain)
- Condensate capacity: 0.8 mL (manual drain version available)
- Pressure gauge range: 0–1.6 MPa
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.6 kg
- Dimensions: 155mm(L) × 60mm(W) × 60mm(H)
- Body material: Die-cast aluminum (anodized finish)
- Seal material: NBR + polycarbonate
- Thread torque limit: 15 N·m max
Industrial-grade combination unit integrating precision filtration (5μm), pressure regulation, and visual pressure monitoring. Features a cyclone separation design with dual-chamber filtration for moisture/oil removal efficiency ≥80%. The bowl incorporates a safety shield and offers 360° rotation for gauge positioning.
- Pneumatic tool air preparation systems
- Packaging machinery compressed air lines
- Semiconductor manufacturing clean air supply
- Dental chair pneumatic controls
- Automated assembly line actuators
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 50mm clearance below bowl for drainage access.
Replace filter element every 6-12 months depending on humidity levels.
| Property | Property Value |
|---|---|
| sku | GPFR20006LJND |
| Port Size | PT1/8 |
