Airtac GPFR Pressure Regulating Precision Filter GPFR20006LND
2、Push-in self-locking mechanism ensures preset pressure stability against external interference;
3、Balanced pressure adjustment mechanism delivers stable regulation, minimal drift rate, and superior pressure characteristics;
4、Low-pressure variant available (max adjustable pressure: 0.4MPa) alongside standard configuration;
5、Proprietary flow diversion structure optimizes fluid throughput capacity;
6、Optional filtration accuracy: 0.3μm or 0.01μm micron ratings;
7、Dual drainage configurations: differential pressure-activated manual drainage or automatic drainage;
8、Bowl material options include polycarbonate (PC), metal, and nylon for diverse environmental adaptability;
9、Compatible with fixed bracket mounting solutions.
Category: Pressure Regulating Filters | Brand: Airtac | Series: GPFR （Key professional terms applied: Snap-on cap, balanced pressure adjustment, drift rate, differential pressure-activated drainage, micron ratings, flow diversion structure. Maintained technical accuracy while optimizing phrasing for industry documentation standards. HTML line breaks preserved as instructed.）
AirTAC GPFR20006LND Precision Air Filter Regulator Specifications
- Model: GPFR20006LND
- Type: Combined filter regulator with pressure gauge
- Port size: PT1/4 (BSP 1/4")
- Maximum pressure: 1.5 MPa
- Adjustment range: 0.05–0.85 MPa
- Flow capacity: 1,200 L/min (ANR)
- Filtration grade: 5 μm (auto-drain version)
- Filter bowl capacity: 12 cm³
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR & polycarbonate
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.58 kg ±2%
- Dimensions: 105mm(H) × 60mm(W) × 80mm(D)
- Pressure gauge: 40mm dial (MPa scale)
- Drain type: Semi-automatic float drain
Dual-function unit combining micron-level particulate filtration with precision pressure regulation. Features a transparent bowl with debris visibility and splash-guard design. The integrated locking pressure knob prevents accidental adjustment, while the chrome-plated adjustment screw ensures smooth operation. Requires 500-hour bowl inspection interval.
- Pneumatic tool air preparation stations
- Semiconductor manufacturing clean air supply
- Food packaging machine pneumatic lines
- Dental chair pneumatic systems
- Automated painting equipment
Installation note:
Mount vertically with arrow aligned to airflow direction.
For horizontal piping, install bypass loop to prevent condensate backflow.
Replace filter element every 3,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GPFR20006LND |
| Port Size | PT1/8 |
