Airtac GPR Precision Pressure Regulator GPR20006L
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR20006L Precision Air Pressure Regulator Specifications
- Model: GPR20006L (Lockable Handle Type)
- Type: Precision pressure regulator with gauge port
- Pressure range: 0.05–0.85 MPa (7–123 PSI)
- Port size: PT1/4 (G1/4 optional)
- Max inlet pressure: 1.5 MPa
- Pressure adjustment: Clockwise rotation decreases pressure
- Body material: Anodized aluminum alloy
- Diaphragm material: NBR rubber
- Operating temperature: -20℃ to 60℃
- Filter requirement: 40μm or finer
- Flow capacity: Cv=0.8 (at 0.5 MPa)
- Weight: 520g ±5%
- Dimensions: 80mm(L) × 50mm(W) × 50mm(H)
- Relief function: Built-in overflow port
- Mounting orientation: Vertical ±15°
High-sensitivity pressure regulator with dual-chamber design for stable output under fluctuating input pressures. Features a tamper-proof locking ring and integrated pressure gauge port for system monitoring. The chrome-plated adjustment knob provides precise 360° rotation with ±2% pressure regulation accuracy.
- Pneumatic automation equipment pressure stabilization
- Packaging machinery tension control systems
- Medical gas pressure regulation devices
- Semiconductor manufacturing tools
- Laboratory pneumatic instrument clusters
Installation protocol:
Install downstream of filter/lubricator unit (FRL). For optimal performance,
maintain airflow direction arrow alignment and bleed residual pressure before
adjustment. Use Teflon tape on male threads only.
| Property | Property Value |
|---|---|
| sku | GPR20006L |
| Port Size | PT1/8 |
