Airtac GPR Precision Pressure Regulator GPR20006MJ
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR20006MJ Precision Pressure Regulator Specifications
- Model: GPR20006MJ
- Type: Precision pressure regulator with gauge
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Adjustable pressure range: 0.02–0.85 MPa
- Maximum flow rate: 2000 L/min (ANR)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR rubber (Viton optional)
- Temperature range: -5℃ to 60℃
- Weight: 0.53 kg ±2%
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H)
- Gauge diameter: 40mm (1.57")
- Pressure gauge range: 0–1.0 MPa
- Protection rating: IP40
- Venting method: Pressure release type
High-sensitivity pressure regulator featuring dual-chamber diaphragm design for stable output under fluctuating input pressures. Includes a stainless steel adjustment knob with torque limiter (0.4–0.6 N·m) and integrated pressure gauge with ±2% full-scale accuracy. Compatible with ISO 6952 flange connections.
- Semiconductor manufacturing equipment
- Precision pneumatic torque tools
- Automated assembly line pressure control
- Medical gas pressure regulation systems
- Food packaging machine air circuits
Installation note:
Mount in vertical orientation with arrow mark aligned to airflow direction.
Requires 5μm pre-filter and weekly condensate drainage.
For pulsation reduction, maintain 10× port diameter upstream piping.
| Property | Property Value |
|---|---|
| sku | GPR20006MJ |
| Port Size | PT1/8 |
