Airtac GPR Precision Pressure Regulator GPR20006MN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR20006MN Precision Air Pressure Regulator Specifications
- Model: GPR20006MN
- Type: Precision pressure reducing valve with gauge
- Port size: PT1/4 (NPT1/4 optional)
- Pressure range: 0.05–0.95 MPa
- Maximum flow: 3000 L/min
- Operating temperature: 0℃ to 60℃
- Accuracy: ±5% of set pressure
- Hysteresis: ≤0.02 MPa
- Weight: 0.5 kg (1.1 lbs)
- Dimensions: 80mm(L) × 52mm(W) × 95mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Filter element: 5μm sintered bronze
- Pressure gauge range: 0–1.0 MPa (standard)
- Mounting orientation: Vertical ±15°
High-precision pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. Includes integrated pressure gauge with shock-resistant lens and ergonomic adjustment knob with torque limiter. The corrosion-resistant construction and T-slot mounting system enable quick installation in confined spaces.
- Precision pneumatic instrumentation calibration
- Automated assembly line pressure control
- Packaging machinery tension regulation
- Semiconductor manufacturing equipment
- Medical gas pressure management systems
- Robotic end-effector control circuits
Installation note:
Always install downstream of main filter/lubricator unit. For optimal performance:
- Maintain ambient temperature below 60℃
- Use with ISO 8573-1 Class 3 compressed air
- Drain condensate weekly via bottom exhaust port
- Allow 30mm clearance for gauge visibility
| Property | Property Value |
|---|---|
| sku | GPR20006MN |
| Port Size | PT1/8 |
