Airtac GPR Precision Pressure Regulator GPR30008HJN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008HJN Precision Pressure Regulator Specifications
- Model: GPR30008HJN
- Type: Precision air pressure regulator with gauge port
- Pressure range: 0.05–0.85 MPa (7–123 PSI)
- Maximum flow rate: 300 L/min (Cv≈0.3)
- Port size: PT1/4 (G1/4 optional)
- Operating temperature: -20℃ to 70℃ (-4°F to 158°F)
- Hysteresis: ≤0.02 MPa
- Weight: 650g (1.43 lbs)
- Dimensions: 48mm(W) × 48mm(D) × 59.5mm(H)
- Body material: Anodized aluminum alloy
- Diaphragm: NBR rubber with fiber reinforcement
- Knob rotation: 310° adjustment range
- Pressure gauge thread: M10×1.0 (optional 1/8NPT)
- Protection rating: IP40
High-sensitivity pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated T-handle allows single-finger micro-adjustment (±0.005 MPa resolution) with anti-vibration lock nut. Includes a 40mm diameter dual-scale gauge (MPa/PSI) with glycerin damping for pulsation reduction.
- Pneumatic servo systems requiring ±1% pressure stability
- Automated assembly line tooling pressure control
- Medical gas pressure regulation in diagnostic equipment
- Semiconductor wafer handling robotics
- Packaging machine air knife pressure management
Installation guidelines:
Mount vertically with arrow direction matching airflow. Use upstream 5μm filter.
For pulsation-sensitive applications, install 200mm downstream tubing before critical components.
Lubricate quarterly with ISO VG32 turbine oil if used in dry air systems.
| Property | Property Value |
|---|---|
| sku | GPR30008HJN |
| Port Size | PT1/4 |
