Airtac GPR Precision Pressure Regulator GPR30008HN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008HN Precision Pressure Regulator Specifications
- Model: GPR30008HN
- Type: Precision pressure regulator with gauge port
- Thread size: PT1/4 (BSPP)
- Pressure range: 0.05–0.85 MPa
- Max flow rate: 3,000 NL/min
- Operating temperature: 0–60℃ (non-freezing)
- Pressure regulation accuracy: ±0.008 MPa
- Repeat accuracy: ±0.005 MPa
- Hysteresis: ≤0.01 MPa
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 450g ±5%
- Dimensions: 98mm(H) × 50mm(W) × 45mm(D)
- Pressure gauge range: 0–1.0 MPa (included)
- Port orientation: Dual side ports (L-shaped flow path)
- Locking mechanism: Push-pull locking knob
High-precision pressure regulation valve with integrated pressure gauge and dust-resistant knob. Features dual-stage filtration (40μm + 5μm mesh) and anti-vibration gauge protection. The self-relieving design allows pressure release without downstream venting. Compatible with ISO 1/4" manifold systems.
- Semiconductor manufacturing equipment
- Precision pneumatic measurement systems
- Automated optical inspection (AOI) machines
- Medical gas pressure control systems
- Robotic end-effector pressure regulation
- Laboratory pneumatic tool stations
Installation note:
Install downstream of main filter regulator (F.R.L. unit). For optimal performance:
- Maintain horizontal mounting position
- Allow 15mm clearance for knob rotation
- Pre-charge system to 0.2MPa before fine adjustment
- Replace filter elements every 2,000 operational hours
| Property | Property Value |
|---|---|
| sku | GPR30008HN |
| Port Size | PT1/4 |
