Airtac GTC Air Treatment Combination GTC20006L
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC20006L Triple Unit (FRL) Technical Specifications
- Model: GTC20006L
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 1,500 L/min (ANR)
- Filtration grade: 5 μm (replaceable sintered element)
- Pressure gauge: 1/8" dial type (0-1.6 MPa range)
- Oil capacity: 130 cm³ (with drip feed adjustment)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Body material: Aluminum alloy (filter bowl: polycarbonate)
- Weight: 1.2 kg (dry), 1.35 kg (with oil)
- Dimensions: 180mm(H) × 65mm(W) × 150mm(D)
- Mounting: Bracket type (panel mount optional)
Integrated air preparation unit combining precision filtration, pressure regulation, and adjustable lubrication. Features a shatter-resistant transparent bowl with auto-drain function and pressure relief lock mechanism. The corrosion-resistant design includes a splash-proof gauge protector and tool-free bowl removal for maintenance.
- Pneumatic tool stations in manufacturing plants
- Automated assembly line air supply systems
- Packaging machinery compressed air conditioning
- CNC machine pneumatic circuit protection
- Industrial robotics air supply units
Installation protocol:
Install vertically with arrow marking aligned to airflow direction.
Maintain 200mm clearance below for bowl removal. Lubricator should
be positioned after equipment using non-lubricated air components.
Recommended maintenance: Replace filter element every 2,000 operating
hours or when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTC20006L |
| Port Size | PT1/8 |
