Airtac GTC Air Treatment Combination GTC20006LW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006LW Technical Specifications
- Model: GTC20006LW
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT3/8 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa
- Maximum pressure: 1.0 MPa
- Filtration rating: 5 μm (with auto-drain)
- Adjustment range: 0.05–0.85 MPa
- Oil capacity: 50 ml (visible reservoir)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 1.2 kg (with full oil)
- Dimensions: 200mm(L) × 100mm(W) × 150mm(H)
- Flow capacity: 2000 l/min (ANR)
- Drain type: Semi-automatic float drain
Professional-grade air preparation unit combining precision filtration, pressure stabilization, and adjustable lubrication. Features a transparent bowl with anti-burst design and 180° rotatable bracket for flexible installation. The integrated pressure gauge includes a damping mechanism for stable readings.
- Pneumatic production line air treatment systems
- CNC machine tool pneumatic circuits
- Automated assembly line actuator control
- Packaging machinery air supply conditioning
- Industrial robot end-effector systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1 MPa.
Use ISO VG32 turbine oil (or equivalent) for lubrication. Drain condensate daily in humid environments.
- Install filter unit closest to air supply inlet
- Mount regulator with pressure gauge facing upward
- Attach lubricator last in the flow path
- Maintain minimum 50mm clearance below drain port
| Property | Property Value |
|---|---|
| sku | GTC20006LW |
| Port Size | PT1/8 |
