Airtac GTC Air Treatment Combination GTC20006SN
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006SN Technical Specifications
- Model: GTC20006SN
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Thread size: PT 1/4 (G1/4 optional)
- Operating pressure range: 0.05-0.85 MPa
- Maximum pressure: 1.0 MPa
- Filter rating: 5 μm (40μm optional element available)
- Adjustable lubricator oil flow: 0-50 drops/min
- Oil cup capacity: 100 cm³
- Temperature range: 5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR/HNBR
- Weight: 0.9 kg (with oil)
- Dimensions: 180mm(H) × 60mm(Dia) × 60mm(W at bracket)
- Pressure gauge: 1/8" dial type (MPa scale)
- Drain type: Manual float drain
Integrated pneumatic conditioning unit combining precision filtration (99.9% water removal), pressure stabilization (±0.02MPa regulation accuracy), and adjustable lubrication. Features anti-clogging sintered bronze filter element and corrosion-resistant aluminum construction. Designed for industrial air line preparation with visual pressure feedback.
- Pneumatic tool air supply systems
- CNC machine pneumatic circuits
- Automated assembly line actuators
- Packaging machinery control systems
- Robotic end-effector air supply
Maintenance protocol:
Drain condensate daily when humidity >60%. Refill oil cup at 1/2 capacity
using ISO VG32 turbine oil. Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GTC20006SN |
| Port Size | PT1/8 |
