Airtac GTC Air Treatment Combination GTC20006SNK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006SNK Technical Specifications
- Model: GTC20006SNK
- Type: Filter-Regulator-Lubricator (FRL) combination unit
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05-1.0 MPa
- Maximum pressure: 1.6 MPa
- Filtration grade: 5 μm (with auto-drain)
- Regulator accuracy: ±0.05 MPa
- Oil droplet size: 5-8 μm (adjustable mist output)
- Flow capacity: 2000 NL/min
- Weight: 1.2 kg (with bracket)
- Dimensions: 200mm(L) × 120mm(W) × 120mm(H)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR & polycarbonate
- Temperature range: -5℃ to 60℃ (non-freezing)
- Drain type: Semi-automatic float drain
- Pressure gauge: Built-in 1/8" gauge port
Modular air preparation unit combining 3-stage filtration, precision pressure regulation, and adjustable lubrication. Features shock-resistant construction with visible bowl design for maintenance monitoring. The S-suffix indicates special nickel-plated components for enhanced corrosion resistance in humid environments.
- Pneumatic production line main air supply
- CNC machine tool pneumatic systems
- Industrial robot end-effector control
- Packaging machinery air circuit protection
- Automotive assembly line tool air supply
Installation guidelines:
Install vertically with arrow marking aligned to airflow direction (max 5° deviation).
Maintain 50mm clearance below drain port. Lubricator should be filled with ISO VG32 oil.
Replace filter element after 5,000 operating hours or when pressure drop exceeds 0.1 MPa.
| Property | Property Value |
|---|---|
| sku | GTC20006SNK |
| Port Size | PT1/8 |
