Airtac GTC Air Treatment Combination GTC20006SW
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006SW Technical Details
- Model: GTC20006SW
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Thread Standard: G1/4 (BSPP)
- Operating Pressure Range: 0.05-1.0 MPa
- Max Flow Rate: 2,000 L/min (ANR)
- Filter Rating: 5 μm (with auto-drain)
- Regulator Accuracy: ±0.2 bar
- Lubricator Oil Capacity: 150 cc (transparent bowl)
- Body Material: Die-cast aluminum (black anodized)
- Seal Material: HNBR (Hydrogenated Nitrile)
- Temperature Range: -5℃ to 60℃ (non-freezing)
- Weight: 1.8 kg (with full oil)
- Dimensions: 180mm(H) × 120mm(W) × 90mm(D)
- Mounting: Bracket or panel (ISO 4414 compliant)
Industrial-grade FRL unit combining 5μm particulate filtration, pressure regulation (±1% FS accuracy), and adjustable lubrication (2-5 drops/min). Features corrosion-resistant construction with impact-resistant polycarbonate bowls and anti-rotation safety lock for regulator knob. Integrated pressure gauge (0-1.6 MPa scale) with glycerin damping.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Packaging machinery air supply conditioning
- Foundry equipment (non-corrosive gas environments)
Maintenance Protocol:
Replace filter element every 2,000 operational hours in normal conditions.
Lubricator requires ISO VG32 or equivalent oil. Bowl torque specification:
3.5-4.0 N·m during reassembly.
| Property | Property Value |
|---|---|
| sku | GTC20006SW |
| Port Size | PT1/8 |
