Airtac GTC Air Treatment Combination GTC20006SWK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20006SWK Technical Specifications
- Model: GTC20006SWK (Compact Aluminum Series)
- Configuration: Filter-Regulator-Lubricator (FRL) combination
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow capacity: 3,500 L/min
- Filter grade: 40μm (5μm optional element available)
- Pressure gauge: 1/8" BSPT dial type (0-1.6 MPa range)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Oil cup capacity: 180cc (transparent polycarbonate)
- Drain type: Manual push-button with splash guard
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Body material: Anodized aluminum alloy (black oxide finish)
- Seal material: NBR/Viton options
- Weight: 1.25 kg (dry, without lubricant)
- Dimensions: 182mm(H) × 102mm(W) × 98mm(D)
- Mounting: Standard 40mm rail mount (ISO 4414 compliant)
Modular FRL unit combining 2nd-stage filtration, precision pressure regulation, and adjustable lubrication. Features automatic drain function with visual contamination indicator window. The ergonomic design allows single-hand pressure adjustment and tool-free bowl removal. Compatible with ISO 8573-1 Class 4 compressed air standards.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated packaging machinery clusters
- Plastic injection molding air circuits
- Automotive assembly line tool stations
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
Lubricator should be refilled when oil level drops below 1/3 capacity. Avoid mounting downstream
of reciprocating compressors without additional pulsation dampers.
| Property | Property Value |
|---|---|
| sku | GTC20006SWK |
| Port Size | PT1/8 |
