Airtac GTC Air Treatment Combination GTC20008L
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triplex Unit GTC20008L Technical Specifications
- Model: GTC20008L
- Type: Filter-Regulator-Lubricator (FRL) combination unit
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05-1.0 MPa
- Maximum pressure: 1.6 MPa
- Filter micron rating: 5 μm (40μm optional element available)
- Lubricator oil capacity: 180 cm³
- Adjustable oil drip rate: 0-30 drops/min
- Flow capacity: 2000 NL/min
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing conditions)
- Weight: 1.25 kg ±5%
- Dimensions: 225mm(H) × 150mm(W) × 105mm(D)
- Mounting: Bracket included for wall/pipeline installation
- Pressure gauge: 63mm dial with dual-scale (MPa/psi)
- Protection rating: IP42 (splash resistant)
Industrial-grade FRL unit combining 3-stage air preparation: automatic drain filter with bowl guard, precision pressure regulator with lockable knob, and sight-feed lubricator. Features anti-clogging filter element and impact-resistant polycarbonate bowl. Includes pressure relief button for safe adjustment.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated assembly equipment clusters
- Packaging machinery air circuit control
- Industrial robot end-effector supply
Installation protocol:
Maintain vertical orientation with arrow markings indicating airflow direction.
Install downstream of main shut-off valve, preceding pneumatic components.
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1MPa.
- Use with ISO 8573-1 Class 3 compressed air
- Pair with automatic drain kit (optional accessory ADK-4)
- For cold environments: Specify low-temperature lubricant (LT-7 oil)
- Vertical clearance: Minimum 50mm below bowl for maintenance
| Property | Property Value |
|---|---|
| sku | GTC20008L |
| Port Size | PT1/4 |
