Airtac GTC Air Treatment Combination GTC20008LK
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Series Triple Unit GTC20008LK Technical Details
- Model: GTC20008LK (F.R.L. combination unit)
- Components: Filter + Regulator + Lubricator
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.9 MPa
- Max flow: 2,000 L/min (ANR)
- Filter rating: 5μm (40μm optional)
- Adjustable pressure: 0.05–0.85 MPa
- Oil feed rate: 0–15 drops/min
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR & polycarbonate
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.2kg (dry, without accessories)
- Dimensions: 190mm(H) × 135mm(W) × 90mm(D)
- Drain type: Manual/auto drain optional
- Pressure gauge: 1/8" dial type (included)
Integrated compressed air treatment unit combining precision filtration, pressure stabilization, and controlled lubrication. Features a corrosion-resistant modular design with visible oil level window and ergonomic pressure adjustment knob. Requires 7-10 bar input pressure for optimal lubrication performance.
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated packaging equipment clusters
- Robotic actuator control circuits
- Semiconductor manufacturing cleanrooms
- Install vertically with flow arrow matching pipeline direction
- Maintain 50cm minimum upstream straight pipe
- Drain condensate daily in high-humidity environments
- Use ISO VG32 turbine oil for lubrication
- Replace filter element at 0.1MPa pressure drop
Critical note:
Never operate without filter element installed. Lubricator function
must be disabled when using non-lubricated cylinders or valves.
| Property | Property Value |
|---|---|
| sku | GTC20008LK |
| Port Size | PT1/4 |
