Airtac GTC Air Treatment Combination GTC20008LN
2. Both water and oil bowls utilize space-saving short-type PC construction, ideal for installations with spatial constraints;
3. Equipped with differential pressure manual drainage mechanism for filter condensation discharge.
Category: FRL Combination Unit , Brand: AirTAC , Series: GTC
AirTAC GTC Triple Unit GTC20008LN Technical Specifications
- Model: GTC20008LN
- Type: Filter-Regulator-Lubricator (FRL) Combination Unit
- Port size: PT1/2 (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Filtration grade: 5 μm (with auto-drain)
- Pressure regulation range: 0.05–0.9 MPa
- Max air flow: 3,500 L/min (ANR)
- Weight: 0.8 kg (dry), 1.1 kg (with oil)
- Dimensions: 150mm(L) × 100mm(W) × 120mm(H)
- Body material: Anodized aluminum alloy (LN series)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (with lubricant), -20℃ to 60℃ (without lubricator)
- Oil capacity: 150 cm³ (transparent polycarbonate bowl)
- Pressure gauge: 1/8" BSPT, 0-1.6 MPa range
- Protection rating: IP54 (standard configuration)
Industrial-grade FRL unit combining 40μm pre-filter, precision pressure regulator, and adjustable micro-lubricator. Features manual drain with dust guard, pressure relief lock mechanism, and impact-resistant bowl. The LN variant uses corrosion-resistant materials for humid environments. Requires upstream installation of larger particulate filter (>5μm).
- Pneumatic production line main air preparation
- CNC machine tool pneumatic systems
- Automated assembly line actuators
- Packaging machinery air supply conditioning
- Industrial robot end-effector control
Installation protocol:
Mount vertically with flow arrow alignment. Maintain minimum 50mm
clearance below drain port. Lubricator should be filled with ISO VG32
or equivalent oil. Replace filter element every 2,000 operational hours.
| Property | Property Value |
|---|---|
| sku | GTC20008LN |
| Port Size | PT1/4 |
